General Specifications
Packaging Details
Technical Specifications
| Property | Standard | Nitco Value |
|---|---|---|
| Deviation in Length | ±0.3% (Max ±1.0 mm) | ±0.1% |
| Deviation in Thickness | ±5% (Max ±0.5 mm) | ±5% |
| Straightness of Edge | ±0.3% (Max ±0.8 mm) | ±0.10% |
| Diagonal Variation (Rectangularity) | ±0.3% (Max ±1.5 mm) | ±0.10% |
| Surface Flatness – Centre Curvature | ±0.4% (Max ±1.8 mm) | ±0.20% |
| Surface Flatness – Edge Curvature | ±0.4% | ±0.20% |
| Surface Flatness – Warpage | ±0.4% | ±0.20% |
| Surface Quality | Min 95% defect-free | Min 95% defect-free |
| Water Absorption | 0.5 < E < 3.0 | < 1.0 |
| Breaking Strength | Min 1300 N | Min 1300 N |
| Modulus of Rupture | >30 N/mm² | >35 N/mm² |
| Abrasion Resistance | Report class | PEI IV Plus |
| Thermal Shock Resistance | No visible defects | Resistant |
| Chemical Resistance | No visible effect | No visible effect |
| Stain Resistance | Manufacturer to state class | Resistant |
| Mohs Scratch Hardness | Min 5 | 6 |
